Our Diamond-Dotted DMD Paper (also known as Diamond-Dotted DMD Insulation Paper) is composed of polyester film and polyester fiber non-woven fabric, bonded with F-grade heat-resistant adhesive (continuous operating temperature up to 155°C). Its surface is coated with diamond-patterned specially modified epoxy resin and undergoes B-stage curing, providing excellent mechanical strength, dielectric properties, adhesion, and heat resistance. Available in thicknesses of 0.10mm, 0.16mm, 0.20mm, 0.25mm, 0.40mm, and 0.50mm, it comes in standard widths of 1000±2mm, 25±2mm, and 50±2mm. This material is primarily used for layer insulation, turn insulation, and end insulation in oil-immersed high-overload transformers, as well as for wrapping copper and aluminum flat wires, ensuring long-term stable performance.
1.Excellent Mechanical Strength: Withstands high mechanical stress without damage, ensuring stability.
2.Good Dielectric Properties: Offers high insulation resistance and breakdown voltage, ensuring the safe operation of electrical equipment.
3.Superior Adhesion: The coating melts at a certain temperature to create adhesion and cures as the temperature rises, bonding adjacent winding layers into a stable unit.
4.Outstanding Heat Resistance: Rated F-class, maintaining reliable insulation performance even under high temperatures.
5.Versatile Processing Options: Available for slitting, slicing, and die-cutting to meet various application needs.
| Index name | Unit | Index value | |||||||||
| Substrate thickness | mm | 0.1 | 0.13 | 0.15 | 0.17 | 0.2 | 0.25 | 0.3 | |||
| Thickness limit deviation | mm | ±0.02 | ±0.03 | ||||||||
| Single-sided adhesive thickness | μm | 5～15 | |||||||||
| Contamination of transformer oil | / | No pollution(△tans<0.001) | |||||||||
| Tensile strength No bending | Vertical | N/10mm | 60 | 90 | ≥100 | ≥120 | ≥140 | ≥190 | ≥270 | ||
| Horizontal | 50 | 80 | ≥90 | ≥105 | ≥120 | ≥170 | ≥200 | ||||
| Elongation at break | Vertical | % | ≥15 | 5 | |||||||
| Horizontal | ≥20 | 5 | |||||||||
| Breakdown voltage, normal | kV | 4 | 5 | 6 | 7 | 9 | 12 | 15 | |||
| Long term heat resistance | / | ≥155 | |||||||||
| Curing conditions | Low temperature 90±5℃, 2h; then high temperature 140±5℃, ≥4h | ||||||||||
| Bond strength | kPa | ≥350 | |||||||||
* For Oil-Immersed Power Transformers: Used as interlayer, turn, and end insulation to enhance dielectric strength and ensure long-term stable operation.
* For Motor Windings: Provides reliable insulation to prevent short circuits between windings, improving motor efficiency and lifespan.
* As a Corona-Resistant Material: Improves electric field distribution in high-voltage equipment, reducing partial discharge and energy loss.
* For Cable Insulation and Shielding: Serves as an isolation layer to prevent electromagnetic interference, enhancing signal stability and system reliability.
* For Electronic Devices: Used in circuit board insulation and protection to ensure proper operation and prevent electrical interference and short circuits.
