NOMEX Type 414 has similar electrical and thermal stability property of NOMEX 410 but with more flexible and conformable sheet with open surface. It is available thicknesses ranging from 0.18 mm (7 mil) to 0.38 mm (15 mil), with specific gravity ranging from 0.9 to 1.0. With excellent features of long term operating high temperature at 220℃ and inherent dielectric strength, Nomex 414 is ideally for the use as slot insulation in hand-wound motors, linear wrapping of wire, as well as main insulation for dry-type transformers where conformability and impregnability are required. It can be also laminated with 3M adhesive tapes like 3M 467, 3M9460PC etc, and then die cut into small parts to provide immediate usage in various of application.
Basic Specification of Nomex 414
Electrical and thermal features similar to Nomex 410
More flexible and conformable sheet with an open surface
Thickness ranging from 0.18 mm (7 mil) to 0.38 mm (15 mil)
Specific gravities ranging from 0.9 to 1.0
UL-94 V0 certificated
Long term operating temperature at 220℃
Chemical solvent resistance and corrosion resistance
Easy to laminate with 3M adhesive Tapes like 3M467MP
Size available in both rolls, sheets and custom die cut shapes
With exceptional thermal stability, outstanding mechanical toughness and inherent dielectric strength, Nomex Paper series are ideally used as a high temperature electrical insulation material in various industries manufacturing. Featuring with more flexible and conformable advantages, Nomex 414 can be used as slot insulation in hand wound motors, linear wrapping of wire, sheet insulation in oil-filled transformers and main insulation for dry type transformers, traction motors, lighting ballasts, welding and mining equipment, etc. Besides, Nomex paper also provides excellent electrical insulation to improve durability and the performance of EV batteries and motors without losing thermal stability.
Here at GBS, we can provide customized Nomex paper in both slit-to-width rolls and custom precision die cut parts or sheet Nomex to meet your specification. Contact us to customize your own solution!
Automotive industries for EV Battery protection
Transformer & Motors Insulation
Wire & Cable Insulation
Controller & Frequency Converter
Power Switch Insulation
Lithium Battery Insulation
LED Lighting & LED Driver
