Formex GL series is the newest formulation of flame retardant polypropylene electrical insulation material belonging to ITW Formex family. It includes GL-10 and GL-17 with thickness of 0.017 inch and 0.010 inch respectively for chosen. Formex GL series shares the same exceptional reliability and durability as GK series while offering more enhanced temperature resistance with 125℃. Formex GL series provides a viable alternative solution to GK when the application requires a thinner gauge material that offers superior temperature tolerance. Till now, GL series material has been widely applied on EV industries, like EV Battery Pack, EV power electronic controller, EV DC Charging, etc,. Here at GBS Tape, we’re available to provide GL-10 and GL-17 material in roll size and also provide precision die cut service for clients easy application.
Basic Specification of GL Series
Thickness: 0.25mm(0.01’’)
Color: Natural/Black
Standard Roll Size: 610mm x 610meter
Roll Weight: 87KG
Thickness: 0.43mm(0.017’’)
Color: Natural/Black
Standard Roll size: 610mm x 305meter
Roll Weight: 78KG
Complies with UL 94 V-0, CSA, IEC, RoHS and WEEE
Service temperatures up to 125℃
H20 Absorption 0.06%
Dielectric Strength 1,880 Volts/mil @ 0.010″
Easy to laminate with 3M adhesive Tapes like 3M467MP
Suitable for die cutting and easy maintenance with flexible characteristics;
High adhesive performance characteristics for graphic printed stably ;
Easy for die cutting or laser cutting to achieve a finished part design
Cost-effective when compared with similar products.
Formex GL series has higher temperature resistance under the same thickness, and it can replace GK series when the application needs thinner and flexible material with higher temperature resistance. The insulation Formex with fabrication expertise, proven quality, efficient pricing, and excellent service to provide the right solution to original equipment manufacturers. Volumes large or small can be accommodated with our diverse equipment for cutting, laminating, forming, printing, and machining. It has been widely applied in various industries like EV Battery Packs, Power Supplies, Transformers, Solar Energy, LED lighting, Cloud Data Center, and other Consumer Electronics Industries, etc.
We can not only provide Formex GL series in both roll size but also offer laminating, die cutting solution as per customer’s different application requests.
Contact us to customize your own solution!
